1 Introduction to the NA-series Programmable Terminals
NA-series Programmable Terminal Hardware User’s Manual (V117)
1-4 Specifications
1
1-4-1 General Specifications
1-4 Specifications
This section gives the hardware specifications of the NA-series PTs.
1-4-1 General Specifications
Item
Specification
NA5-15W
NA5-15U
NA5-12W
NA5-12U
NA5-9W
NA5-9U
NA5-7W
NA5-7U
Rated supply
voltage
24 VDC
Allowable power
supply voltage
range
19.2 to 28.8 VDC (24 VDC ±20%)
Allowable
momentary
power interrup-
tion time
Operation for momentary power interruption is not specified.
Power con-
sumption
47 W max. 45 W max. 40 W max. 35 W max.
Ambient operat-
ing temperature
0 to 50°C
*1*2
Ambient stor-
age temperature
−20 to 60°C
*3
Ambient operat-
ing humidity
10 to 90%
*2
Must be no condensation.
Atmosphere Must be free from corrosive gases.
Pollution degree 2 or less: JIS B 3502, IEC 61131-2
Noise immunity 2 kV on power supply line (Conforms to IEC 61000-4-4.)
Vibration resis-
tance (during
operation)
Conforms to IEC 60068-2-6.
5 to 8.4 Hz with 3.5-mm half amplitude and 8.4 to 150 Hz with 9.8 m/s
2
for 100 minutes each
in X,Y, and Z directions (Time coefficient of 10 minutes × coefficient factor of 10 = total time
of 100 min.)
Shock resis-
tance (during
operation)
Conforms to IEC 60028-2-27.
147 m/s
2
3 times each in X, Y, and Z directions
Dimensions
420 × 291 × 69 mm
(W × H × D)
340 × 244 × 69 mm
(W × H × D)
290 × 190 × 69 mm
(W × H × D)
236 × 165 × 69 mm (W
× H × D)
Panel cutout
dimensions
392 × 268 mm
(horizontal × vertical)
Panel thickness: 1.6
to 6.0 mm
310 × 221 mm
(horizontal × vertical)
Panel thickness: 1.6
to 6.0 mm
261 × 166 mm
(horizontal × vertical)
Panel thickness: 1.6
to 6.0 mm
197 × 141 mm
(horizontal × vertical)
Panel thickness: 1.6 to
6.0 mm
Weight 3.2 kg max. 2.3 kg max. 1.7 kg max. 1.3 kg max.
Degree of pro-
tection
Front-panel controls: IP65 oil-proof type, UL Type 4X (at initial state)
To reinstall the NA Unit in a panel, contact your OMRON representative for replacement of
the rubber packing.
Battery life
Battery life: 5 years at 25°C
The RTC will be backed up for 5 days after the battery runs low. The RTC will be backed up
by a super capacitor for 5 minutes after removing the old battery.
(This assumes that the power is first turned ON for at least 5 minutes and then turned OFF.)
+1
0
+1
0
+1
0
+1
0
+1
0
+1
0
+0.5
0
+0.5
0
