1 Introduction to the NA-series Programmable Terminals
1 - 8
NA-series Programmable Terminal Hardware User’s Manual (V117)
International
standards
*4
UL 508/CSA standard C22.2 No.142
*5
EMC Directive (2004/108/EC) EN 61131-2:2007
Shipbuilding standards LR, DNV, and NK
IP65 oil-proof, UL Type 4X (front panel only)
ANSI 12.12.01 Class 1 Division 2/CSA standard C22.2 No. 213-M1987 (R2013)
RoHS Directive (2002/95/EC)
KC Standards KN 61000-6-2:2012-06 for EMS and KN 61000-6-4:2012-06 for EMI
RCM
*1. The ambient operating temperature is subject to the following restrictions, depending on the mounting angle.
• The ambient operating temperature is 0° to 40°C when the mounting angle is 0° or more and less than 45°
to the horizontal.
• The ambient operating temperature is 0° to 50°C when the mounting angle is 45° or more and 90° or less
to the horizontal.
• The ambient operating temperature is 0° to 50°C when the mounting angle is 90° or more and 135° or less
to the horizontal.
*2. Use the PT within the following temperature and humidity ranges.
Item
Specification
NA5-15W
NA5-15U
NA5-12W
NA5-12U
NA5-9W
NA5-9U
NA5-7W
NA5-7U
50
°
C
50
°
C
40
°
C
40
°
C
50
°
C
90
°
to 135
°
45
°
to 90
°
0
°
to 45
°
50
°
C
50
°
C
Temperature [°C]
Humidity [%]
0
10
20
30
40
50
60
70
80
90
100
-10 0 10 20 30 40 50 60
Operating
temperature-humidity
range
