1 - 11
1 Introduction to the NA-series Programmable Terminals
NA-series Programmable Terminal Hardware Users Manual (V117)
1-4 Specifications
1
1-4-2 Performance Specifications
*1. The serial port and Expansion Unit connector are for future expansion.
External Interfaces
Item Specifications (Same for all models.)
Ethernet ports Applications Port 1: Connecting to anything other than the Sysmac Studio,
e.g., device connections and VNC clients
Port 2: Connecting to the Sysmac Studio in addition to the
applications of port 1.
Number of ports 2 ports
Compliant standards IEEE 802.3i (10BASE-T), IEEE 802.3u (100BASE-TX), and
IEEE 802.3ab (1000Base-T)
Transmission media Shielded twisted-pair (STP) cable: Category 5, 5e, or higher
Transmission dis-
tance
100 m
Connector RJ-45 8P8C modular connector
USB host ports Applications USB Memory Device, keyboard, or mouse
Number of ports 2 ports
Compliant standards USB 2.0
Transmission dis-
tance
5 m max.
Connector Type-A connector
USB slave port Applications Sysmac Studio connection
Number of ports 1 port
Compliant standards USB 2.0
Transmission dis-
tance
5 m max.
Connector Type-B connector
Serial port
*1
Applications Device Connection
Number of ports 1 port
Compliant standards RS-232C
Transmission dis-
tance
15 m max.
Connector D-SUB 9-pin female connector
SD Memory Card slot Applications To transfer or store the project or to store log data.
Number of slots 1 slot
Compliant standards SD/SDHC
Expansion Unit con-
nector
*1
Applications Expansion Unit
Quantity 1
