Omron NA5-12W series

2 Configuration Units
2 - 4
NA-series Programmable Terminal Hardware User’s Manual (V117)
Back Panel
(a) Battery cover
• Back Panel
• Bottom Panel
(c) SD Memory
Card connector
(d) Ethernet ports
12
(h) Reset switch
(e) Serial port (for future expansion)
(f) USB host port
(g) USB slave port
(b) Expansion Unit
connector (for
future expansion)
(l) DC input
terminals
(m) ID information label
(i) Battery connector
(k) Battery
(j) DIP switch
(Appearance
with the Battery Cover Open)
