Related Manuals
NA-series Programmable Terminal Hardware User’s Manual (V117)
Related Manuals
The following manuals are related to the NA-series PTs. Use these manuals for reference.
Manual name Cat. No. Models Applications Description
NA-series Program-
mable Terminal Hard-
ware User’s Manual
V117 NA5-W
Learning the speci-
fications and set-
tings required to
install an NA-series
PT and connect
peripheral devices.
Information is provided on NA-series
PT specifications, part names, instal-
lation procedures, and procedures to
connect an NA Unit to peripheral
devices.
Information is also provided on main-
tenance after operation and trouble-
shooting.
NA-series Program-
mable Terminal Soft-
ware User’s Manual
V118 NA5-W
Learning about
NA-series PT
pages and object
functions.
NA-series PT pages and object func-
tions are described.
NA-series Program-
mable Terminal
Device Connection
User’s Manual
V119 NA5-W Learning the speci-
fications required
to connect devices
to an NA-series
PT.
Information is provided on connec-
tion procedures and setting proce-
dures to connect an NA-series PT to
a Controller or other device.
NA-series Program-
mable Terminal
Startup Guide
V120 NA5-W Learning in con-
crete terms infor-
mation required to
install and start the
operation of an
NA-series PT.
The part names and installation pro-
cedures are described followed by
page creation and transfer proce-
dures with the Sysmac Studio. Also
operation, maintenance, and inspec-
tion procedures after the project is
transferred are described. Sample
screen captures are provided as
examples.
NX-series CPU Unit
Hardware User's
Manual
W535 NX701- Learning the basic
specifications of
the NX-series CPU
Units, including
introductory infor-
mation, designing,
installation, and
maintenance.
Mainly hardware
information is pro-
vided.
An introduction to the entire
NX-series system is provided along
with the following information on the
CPU Unit.
• Features and system configuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspection
Use this manual together with the
NJ/NX-series CPU Unit Software
User's Manual (Cat. No.W501).
To Next Page
