1 Introduction to the NA-series Programmable Terminals
1 - 10
NA-series Programmable Terminal Hardware User’s Manual (V117)
*1. There may be some defective pixels in the display. This is not a fault as long as the numbers of defective light
and dark pixels fall within the following standard ranges.
*2. The backlight can be replaced at an OMRON maintenance base.
*3. This is the estimated time before brightness is reduced by half at room temperature and humidity. The life
expectancy is drastically shortened if PT is used at high temperatures.
*4. The brightness of the front panel indicators is also adjustable when you adjust the brightness of the backlight.
*1. Each function key has blue indicator. The brightness of the function key indicators is also adjustable when you
adjust the brightness of the backlight.
1-4-2 Performance Specifications
Display
Item
Specification
NA5-15W NA5-12W NA5-9W NA5-7W
Display
panel
*1
Display
device
TFT LCD
Screen size 15.4 inches 12.1 inches 9.0 inches 7.0 inches
Resolution 1,280 × 800 dots (horizontal × vertical) 800 × 480 dots (horizontal × vertical)
Colors 16,770,000 colors
Effective
display area
331 × 207 mm (hor-
izontal × vertical)
261 × 163 mm (hor-
izontal × vertical)
197 × 118 mm (hor-
izontal × vertical)
152 × 91 mm (hori-
zontal × vertical)
View angles Left: 60°, Right: 60°, Top: 60°, Bottom: 60°
Backlight
*2
Life
50,000 hours min.
*3
Brightness
adjustment
200 levels
Front panel
indicators
*4
RUN Lit green: Normal operation
Lit red: Error
Model Standard range
NA5-15W
NA5-12W
NA5-9W
NA5-7W
Number of light and dark pixels: 10 or less. (There
must not be 3 consecutive light/dark pixels.)
Operation
Item
Specification
NA5-15W NA5-12W NA5-9W NA5-7W
Touch panel Method: Analog resistance membrane (pressure sensitive)
Resolution: 16,384 × 16,384
Life: 1,000,000 operations
Function keys
*1
3 inputs (capacitance inputs)
Data Capacity
Item
Specification
NA5-15W NA5-12W NA5-9W NA5-7W
User data capacity 256 MB
