4 - 39
4 System Program
NA-series Programmable Terminal Hardware User’s Manual (V117)
4-4 System Menu Details
4
4-4-14 Transfer Operations (Device System Menu)
This screen is used to upload the project to an SD Memory Card or USB Memory Device.
Precautions for Correct Use
Projects that are downloaded with Sysmac Studio version 1.10 and projects that are down-
loaded when the Transfer source code to the NA device Check Box is not selected cannot be
read by the Sysmac Studio.
You can use projects like these (i.e., projects that do not contain the source code) to create
duplicates of the NA Unit with the same project or as backups to restore the NA Unit without
using a computer if the NA Unit fails.
Transfer User Program from HMI
No. Item Description
(a) Destination Media Sets the media to which to upload the project.
(b) Path Displays the path of the folder displayed at (c).
(c) Current Folder Displays the files and folders in the currently open folder.
(d) Destination File Sets the file name.
(e) Transfer from HMI Uploads the selected project from the HMI to the destination media.
To Next Page
