4-4-14 Transfer Operations (Device System Menu)
This screen is used to upload recipes, videos, or other data to an SD Memory Card or USB Memory
Device.
Transfer Data from HMI
No. Item Description
(a) Media Sets the media to which to upload the data.
(b) Path Displays the path of the folder displayed at (c).
(c) Destination Folder Displays the files and folders in the currently open destination
folder.
(d) File Name Sets the name of the file at the destination.
(e) Transfer from HMI Uploads the data.
(f) Target Files Displays a list of the files that you can upload.
(g) Data Type Sets the file type. Only files with the specified file type are displayed
at (c) and (f).
(g)
(e)
(f)
(a)
(b)
(c)
(d)
