4 System Program
4 - 44
NA-series Programmable Terminal Hardware User’s Manual (V117)
A color bar is displayed. Use this to check the LCD.
Tap the screen to move to the next display.
This screen is used to calibrate the touch panel. Tap the plus signs that are displayed.
To cancel, double-tap any position.
LCD Display
Touch Panel Calibration
