Omron NX-AD series User Manual

6 - 7
6 Analog Input Units
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
6-3 Specifications of I/O Data
6
6-3-1 Allocable I/O Data
z Eight-point Input Units
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Ch1 Analog Input
Value
Value of analog input 1 INT 0 Ch1 Analog
Input Value
6000 hex 01 hex
Ch2 Analog Input
Value
Value of analog input 2 INT 0 Ch2 Analog
Input Value
02 hex
Ch3 Analog Input
Value
Value of analog input 3 INT 0 Ch3 Analog
Input Value
03 hex
Ch4 Analog Input
Value
Value of analog input 4 INT 0 Ch4 Analog
Input Value
04 hex
Ch5 Analog Input
Value
Value of analog input 5 INT 0 Ch5 Analog
Input Value
05 hex
Ch6 Analog Input
Value
Value of analog input 6 INT 0 Ch6 Analog
Input Value
06 hex
Ch7 Analog Input
Value
Value of analog input 7 INT 0 Ch7 Analog
Input Value
07 hex
Ch8 Analog Input
Value
Value of analog input 8 INT 0 Ch8 Analog
Input Value
08 hex
