7 Analog Output Units
7 - 10
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
This function skips the conversion processing and error detection processing for unused outputs, and
shortens the conversion time.
Normally in this Unit, the output set values for the number of input points mounted are converted in
sequence. The setting can be changed so that unused outputs are not converted.
By reducing the number of conversion points, the conversion time is shortened.
Whether the channel is enabled or disabled is settable for each output.
However, set the Ch Enable/Disable parameter to Enable for at least one channel for a Unit.
If you disabled all channels for a Unit, an NX Unit Initialization Error event (event code: 84C10000 hex)
occurs.
Refer to the user's manual for the Communications Coupler Unit for details on events.
z Two-point Output Units
z Four-point Output Units
All Analog Output Units
7-5-2 Selecting Channel To Use
Purpose
Details on the Function
Setting name Description
Default
value
Unit
Ch1 Enable/Disable Set to enable or disable the channel.
FALSE: Disable
TRUE: Enable
TRUE ---
Ch2 Enable/Disable TRUE ---
Setting name Description
Default
value
Unit
Ch1 Enable/Disable Set to enable or disable the channel.
FALSE: Disable
TRUE: Enable
TRUE ---
Ch2 Enable/Disable TRUE ---
Ch3 Enable/Disable TRUE ---
Ch4 Enable/Disable TRUE ---
