6 - 13
6 Analog Input Units
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
6-5 Function
6
6-5-2 Selecting Channel To Use
This function skips the conversion processing and error detection processing for unused inputs, and
shortens the conversion time.
Normally in this Unit, the input signals for the number of input points are converted in sequence. The
setting can be changed, so that unused inputs are not converted.
By reducing the number of conversion points, the conversion time is shortened.
Whether the channel is enabled or disabled is settable for each input.
However, set the Ch Enable/Disable parameter to Enable for at least one channel for a Unit.
If you disabled all channels for a Unit, an NX Unit Initialization Error event (event code: 84C10000 hex)
occurs.
Refer to the user's manual for the Communications Coupler Unit for details on events.
z Two-point Input Units
z Four-point Input Units
6-5-2 Selecting Channel To Use
Purpose
Details on the Function
Setting name Description
Default
value
Unit
Ch1 Enable/Disable Set to enable or disable the channel.
FALSE: Disable
TRUE: Enable
TRUE ---
Ch2 Enable/Disable TRUE ---
Setting name Description
Default
value
Unit
Ch1 Enable/Disable Set to enable or disable the channel.
FALSE: Disable
TRUE: Enable
TRUE ---
Ch2 Enable/Disable TRUE ---
Ch3 Enable/Disable TRUE ---
Ch4 Enable/Disable TRUE ---
