Omron NX-AD series User Manual

8 Troubleshooting
8 - 8
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
14C00000 hex Unit Calibra-
tion Value
Parity Error
An error occurred in
the user calibration
data in the NX Unit.
• An error was detected in the
calibration data.
SP. 8-17
65030000 hex Unit I/O Dis-
connection
Detected for
Channel 1
A disconnected
input was detected
for channel 1.
• Input wiring is broken.
• Input wiring is disconnected.
SU P. 8-17
65040000 hex Unit I/O Dis-
connection
Detected for
Channel 2
A disconnected
input was detected
for channel 2.
• Input wiring is broken.
• Input wiring is disconnected.
SU P. 8-18
65050000 hex Unit I/O Dis-
connection
Detected for
Channel 3
A disconnected
input was detected
for channel 3.
• Input wiring is broken.
• Input wiring is disconnected.
SU P. 8-18
65060000 hex Unit I/O Dis-
connection
Detected for
Channel 4
A disconnected
input was detected
for channel 4.
• Input wiring is broken.
• Input wiring is disconnected.
SU P. 8-19
65070000 hex Unit I/O Dis-
connection
Detected for
Channel 5
A disconnected
input was detected
for channel 5.
• Input wiring is broken.
• Input wiring is disconnected.
SU P. 8-19
65080000 hex Unit I/O Dis-
connection
Detected for
Channel 6
A disconnected
input was detected
for channel 6.
• Input wiring is broken.
• Input wiring is disconnected.
SU P. 8-20
65090000 hex Unit I/O Dis-
connection
Detected for
Channel 7
A disconnected
input was detected
for channel 7.
• Input wiring is broken.
• Input wiring is disconnected.
SU P. 8-20
650A0000 hex Unit I/O Dis-
connection
Detected for
Channel 8
A disconnected
input was detected
for channel 8.
• Input wiring is broken.
• Input wiring is disconnected.
SU P. 8-21
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
