Omron NX-AD series User Manual

A - 41
Appendices
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
A-3 List of NX Objects
A
A-3-2 Analog Input Units
These objects accept I/O allocations.
You cannot access the objects that are described below with the Read NX Unit Object instruction, Write
NX Unit Object instruction, or other messages.
*1. The default value and data range for Number of Entries are as follows.
Objects That Accept I/O Allocations
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6000 --- Analog Input Value --- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Ch1 Analog Input Value 0 -32768 to
32767
--- INT RO Pos-
sible
---
02 Ch2 Analog Input Value 0 -32768 to
32767
--- INT RO Pos-
sible
---
03 Ch3 Analog Input Value 0 -32768 to
32767
--- INT RO Pos-
sible
---
04 Ch4 Analog Input Value 0 -32768 to
32767
--- INT RO Pos-
sible
---
05 Ch5 Analog Input Value 0 -32768 to
32767
--- INT RO Pos-
sible
---
06 Ch6 Analog Input Value 0 -32768 to
32767
--- INT RO Pos-
sible
---
07 Ch7 Analog Input Value 0 -32768 to
32767
--- INT RO Pos-
sible
---
08 Ch8 Analog Input Value 0 -32768 to
32767
--- INT RO Pos-
sible
---
NX Units Default value Data range
NX-AD2203/AD2204/AD2208/
AD2603/AD2604/AD2608
22
NX-AD3203/AD3204/AD3208/
AD3603/AD3604/AD3608/
44
NX-AD4203/AD4204/AD4208/
AD4603/AD4604/AD4608/
88
Other models 0 0
