4 Installation and Wiring

4 - 16

NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)

This section describes how to connect and remove wires.

z Terminal Block Parts and Names

z Required Tools

Use a flat-blade screwdriver to connect and remove wires.

Use the following flat-blade screwdriver.

Recommended screwdriver

Connecting/Removing Wires

Model Manufacturer

SZF 0-0,4×2,5 Phoenix Contact

Terminal hole

Release hole

2.5 mm0.4 mm

Front view

8 to 12

Side view

2.5-mm dia.
