6 - 17
6 Digital Input Units
NX-series Digital I/O Unit User’s Manual (W521)
6-4 Function
6
6-4-2 Input Filter
The Digital Input Units that support switching Free-Run refreshing and Synchronous I/O refreshing.
You cannot use this function for the NX Units that support input refreshing with input changed time.
This section describes how to configure settings with the Sysmac Studio.
When you are using Support Software other than the Sysmac Studio, in the Edit Unit Operation Set-
tings Tab Page, set the parameters described in the procedure and transfer the settings to the target
NX Unit.
For details on how to display the Edit Unit Operation Settings Tab Page and to transfer settings to an
NX Unit with Support Software other than the Sysmac Studio, refer to the operation manual for the Sup-
port Software that you are using.
1 Display the Edit Unit Operation Settings Tab Page.
For the display methods, refer to A-9 Displaying the Edit Unit Operation Settings Tab Page on
page A-164.
2 Select the filter time you want to set from the upper list of Input Filter Setting.
3 Select the input filter mode you want to set from the lower list of Input Filter Setting.
Target NX Units
Setting Method
To Next Page
