6 Digital Input Units
6 - 18
NX-series Digital I/O Unit User’s Manual (W521)
• If you set a value different from the default value, the Value on the Sysmac Studio is dis-
played in a different color.
• You can click the Return to Default Value Button to return all set values on the Sysmac Stu-
dio to the default values.
• Help for the settings is displayed at the bottom of the Edit Unit Operation Settings Tab Page.
4 Click the Transfer to Unit Button.
The settings are transferred from the Sysmac Studio to the NX Unit.
The settings are reflected after the Unit is restarted.
The Unit is required to restart after the transfer of Unit operation settings on the Support Soft-
ware is completed. Always sufficiently check the safety at the connected devices before you
transfer the Unit operation settings.
Note that when you use this function, the time for which the input value actually turns ON or turns OFF
is delayed from the initial input to the input terminals until ON delay time or OFF delay time in the follow-
ing table.
Precautions
Delay time Description
ON delay time ON response time + input filter time
OFF delay time OFF response time + input filter time
