A - 53
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-1 Data Sheet
A
A-1-3 Digital Output Units
Terminal connection
diagram
Disconnec-
tion/Short-circuit
detection
Not supported. Protective function With load short-circuit protection.
OUT0
IOG0
IOV2
IOV0
A1 B1
A8 B8
OUT2
IOG2
OUT1
IOG1
IOV3
IOV1
OUT3
IOG3
COM (+V) COM (+V)
0V 0V
Transistor Output Unit
NX-OD3268
Two-wire type
Three-wire type
24 V
DC
• 0V has 2 terminals, so be sure to wire both terminals.
• COM (+V) has 2 terminals, so be sure to wire both terminals.
