Appendices
A - 136
NX-series Digital I/O Unit User’s Manual (W521)
These objects accept I/O allocations.
You cannot access the objects that are described below with the Read NX Unit Object instruction, Write
NX Unit Object instruction, or other messages.
*1. The default value and data range for Number of Entries are as follows.
Objects That Accept I/O Allocations
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6000 --- Bit Input --- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Input Bit 00 FALSE TRUE or
FALSE
--- BOOL RO Pos-
sible
---
02 Input Bit 01 FALSE TRUE or
FALSE
--- BOOL RO Pos-
sible
---
03 Input Bit 02 FALSE TRUE or
FALSE
--- BOOL RO Pos-
sible
---
04 Input Bit 03 FALSE TRUE or
FALSE
--- BOOL RO Pos-
sible
---
NX Units Default value Data range
NX-ID3317/ID3343/ID3417/ID3443/
ID3344/ID3444/IA3117
44 (fixed)
Other models 0 0 (fixed)
