A - 137
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-5 List of NX Objects
A
A-5-2 Digital Input Units
*1. The default value and data range for Number of Entries are as follows.
*2. Detailed data for Input Bit 8 bits are as follows.
Bit 0: Input Bit 00
Bit 1: Input Bit 01
·
·
·
Bit 7: Input Bit 07
*1. The default value and data range for Number of Entries are as follows.
*2. Detailed data for Input Bit 16 bits are as follows.
Bit 0: Input Bit 00
Bit 1: Input Bit 01
·
·
·
Bit 15: Input Bit 15
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6001 --- BYTE Input --- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Input Bit 8 bits 00 hex
00 to FF hex
*2
--- BYTE RO Pos-
sible
---
NX Units Default value Data range
NX-ID4342/ID4442 1 1 (fixed)
Other models 0 0 (fixed)
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6002 --- Word Input --- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Input Bit 16 bits 0000 hex 0000 to FFFF
hex
*2
--- WORD RO Pos-
sible
---
NX Units Default value Data range
NX-ID5142-1/ID5142-5/ID5342/ID5442 1 1 (fixed)
Other models 0 0 (fixed)
