A - 147
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-5 List of NX Objects
A
A-5-3 Digital Output Units
*1. The default value and data range for Number of Entries are as follows.
*2. The meaning of the set values for Output BitOutput Status is as follows.
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6011 --- Specified Time Stamp Out-
put Status
--- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Output Bit 00 Output Sta-
tus
FALSE TRUE or
FALSE
*2
--- BOOL RO Pos-
sible
N
02 Output Bit 01 Output Sta-
tus
BOOL RO Pos-
sible
N
NX Units Default value Data range
NX-OD2154/OD2258 2 2 (fixed)
Other models 0 0 (fixed)
Set value Meaning
FALSE Output completion
TRUE Waiting for output to refresh
