Appendices
A - 148
NX-series Digital I/O Unit User’s Manual (W521)
This section lists other objects.
*1. The default value and data range for Number of Entries are as follows.
*2. The meaning of the set values for Load Rejection Output for Output Bit  is as follows.
Other Objects
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
5010 --- Load Rejection Output Set-
ting
--- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Load Rejection Output for
Output Bit 00
FALSE TRUE or
FALSE
*2
--- BOOL RW Not
pos-
sible
Y
02 Load Rejection Output for
Output Bit 01
FALSE --- BOOL RW Not
pos-
sible
Y
03 Load Rejection Output for
Output Bit 02
FALSE --- BOOL RW Not
pos-
sible
Y
04 Load Rejection Output for
Output Bit 03
FALSE --- BOOL RW Not
pos-
sible
Y
NX Units Default value Data range
NX-OD3121/OD3153/OD3256/OD3257/
OD3268
4 4 (fixed)
NX-OC2633/OC2733 2 2 (fixed)
Other models 0 0 (fixed)
Set value Meaning
FALSE OFF
TRUE Hold the present value.
