Omron NX1P2 series User Manual

6 Troubleshooting
6 - 28
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
10320000 hex SD Memory
Card Pro-
gram Trans-
fer Failed to
Start
An error was
detected in pre-start
checks for transfer-
ring SD Memory
Card programs.
• Program transfer by system-
defined variable is set to Do not
use in the Controller Setup.
• Password of Program transfer
by system-defined variable in
the Controller Setup does not
agree with the _Card1Prg-
TransferCmd.Password sys-
tem-defined variable.
•
The DIP switch on the CPU Unit
is not set to allow starting the SD
Memory Card program transfer.
• An SD Memory Card is not
inserted.
• The SD Memory Card type is
not correct.
• The format of the SD Memory
Card is not correct.
•
There is no such folder on the
SD Memory Card as specified by
the _Card1PrgTransferCmd.Dir-
Name system-defined variable.
• There are no backup files in
such a folder on the SD Mem-
ory Card as specified by the
_Card1PrgTransferCmd.Dir-
Name system-defined variable.
•
Either the backup files in the
folder specified by the _Card1Prg-
TransferCmd.DirName system-
defined variable on the SD Mem-
ory Card are corrupted or required
data is not in the backup files on
the SD Memory Card.
• The unit version of the CPU
Unit to which to transfer the
files is older than the unit ver-
sion of the backup files on the
SD Memory Card.
• The model of the CPU Unit to
which to transfer the files is not
the same as the model of the
CPU Unit of the backup files on
the SD Memory Card.
•
The CPU Unit is write-protected.
• Another backup operation is in
progress.
• Synchronization, online editing,
or the Clear All Memory opera-
tion is in progress.
• Required files are not set to
transfer in the setting of the
_Card1PrgTransferCmd sys-
tem-defined variable.
• Reading the data for the SD
Memory Card program transfer
failed because the SD Memory
Card is faulty or not formatted
correctly.
•
The SD Memory Card is damaged.
• The database connection ser-
vice version of the CPU Unit to
which to transfer the files is older
than the database connection
service version of the backup
files on the SD Memory Card.
S page 6-82
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info

Omron NX1P2 series Specifications

General

Model	NX1P2 Series
Manufacturer	Omron
Type	Controller
CPU Units	1
Program Capacity	5 MB
Data Memory Capacity	128 KB
Ethernet Ports	1
Serial Ports	1
Built-in EtherNet/IP Port	Yes
Built-in EtherCAT Port	Yes
Built-in USB Port	Yes
SD Memory Card Slot	Yes
USB Port	1
Power Supply Voltage	24 VDC
Programming Language	Ladder, Structured Text, Function Block Diagram
Communication Protocols	EtherNet/IP, EtherCAT, Serial (RS-232C)
