No.18S111-03
14/70
STC-MBS500POE / STC-MCS500POE
Product Specifications and User’s Guide
IR Cut Filter (STC-MCS500POE)
5.3 Mechanical Specifications
Model Number STC-MBS500POE STC-MCS500POE
Dimensions
29 (W) x 29 (H) x 53 (D) mm (*1)
Optical Filter
No Optical Filter IR Cut Filter
Optical Center Accuracy
Positional accuracy in Horizontal and Vertical directions: +/- 0.5 mm
Rotational accuracy of Horizontal and Vertical: +/- 1.5 deg.
Material
Aluminum Alloy (AC)
Lens Mount C mount
Interface Connectors
Ethernet connector: RJ45 connector
Power- I/O connector: HR10A-7R-6PB (Hirose) or equivalent
Camera Mounting Six M3 screw holes (Two on top, four on bottom plate)
Weight
Approximately 65 g
(*1) Excluding the connectors
