No.18S111-03
43/70
STC-MBS500POE / STC-MCS500POE
Product Specifications and User’s Guide
Auto shutter
The brightness of image maintains to keep target brightness with shutter automatically.
If the brightness of image is darker than target brightness, exposure time extends up to
“Exposure Auto Limit Max”.
If the brightness of image is brighter than target brightness, exposure time becomes shorter up to
“Exposure Auto Limit Min”.
GenICam Parameters
ExposureAuto IEnumeration Type
Auto shutter ON / OFF selection
Selection: “ON” (Continuous), “OFF” (Off)
Default: “OFF”
ExposureAutoLimitMin
IFloat Type Minimum exposure time (in µsecond) for auto shutter
Range: 1 to 16,777,215
Default: 14
ExposureAutoLimitMax
IFloat Type Maximum exposure time (in µsecond) for auto shutter
Range: 1 to 16,777,215
Default: 45,345
ALC settings procedure
ALC Settings Procedure
1. Sets “Auto Luminance Width”, “Auto Luminance Height”, “Auto Luminance Offset X”,
“Auto Luminance Offset Y” and “Auto Luminance Weight” for “Auto Luminance Region 0 to 8”.
2. Sets “Continuous” for “Gain Auto” when using AGC function.
3. Sets “Gain Auto Limit Min” and “Gain Auto Limit Max” when using AGC function.
4. Sets “Continuous” for “Exposure Auto” when using auto shutter function.
5. Sets “Exposure Auto Limit Min” and “Exposure Auto Limit Max” when using auto shutter function.
6. Sets “Auto Luminance Target”.
To Next Page
