11.4 AnalogControl
Name Description
GainSelector Selects which Gain is controlled by the various Gain features.
Gain [GainSelector] Controls the selected gain as an absolute physical value.
GainAuto [GainSelector] Sets the automatic gain control (AGC) mode.
GainAutoLimitMin [GainSelector] Determine the lower limit of gain when Gain Auto is set to Continuous.
GainAutoLimitMax [GainSelector] Determine the upper limit of gain when Gain Auto is set to Continuous.
AutoLuminanceTarget Target brightness for auto luminance control.
AutoLuminanceRegionSelector Select the area for auto luminance control.
AutoLuminanceWidth
[AutoLuminanceRegionSelector]
Determine width of targeted region for auto luminance control.
AutoLuminanceHeight
[AutoLuminanceRegionSelector]
Determine height of targeted region for auto luminance control.
AutoLuminanceOffsetX
[AutoLuminanceRegionSelector]
Determine X offset of targeted region for auto luminance control.
AutoLuminanceOffsetY
[AutoLuminanceRegionSelector]
Determine Y offset of targeted region for auto luminance control.
AutoLuminanceWeight
[AutoLuminanceRegionSelector]
Weight of the area determined by Auto Luminance Region Selector for
auto luminance control.
AutoLuminancePeak Ratio of peak and average for auto luminance control.
BlackLevelSelector Selects which Black Level is controlled by the various Black Level
features.
BlackLevel [BlackLevelSelector] Controls the analog black level as an absolute physical value.
DigitalGainOffsetMode Digital Gain Offset Mode is enabled.
BalanceRatioSelector Selects which Balance ratio to control. (STC-MCS500POE)
BalanceRatio [BalanceRatioSelector] Controls ratio of the selected color component to a reference color
component. (STC-MCS500POE)
BalanceWhiteAuto Controls the mode for automatic white balancing between the color
channels. (STC-MCS500POE)
BalanceWhiteAutoRegionSelector Select the area for auto white balance. (STC-MCS500POE)
BalanceWhiteAutoWidth
[BalanceWhiteAutoRegionSelector]
Determine width of targeted region for auto white balance.
(STC-MCS500POE)
BalanceWhiteAutoHeight
[BalanceWhiteAutoRegionSelector]
Determine height of targeted region for auto white balance.
(STC-MCS500POE)
BalanceWhiteAutoOffsetX
[BalanceWhiteAutoRegionSelector]
Determine X offset of targeted region for auto white balance.
(STC-MCS500POE)
BalanceWhiteAutoOffsetY
[BalanceWhiteAutoRegionSelector]
Determine Y offset of targeted region for auto white balance.
(STC-MCS500POE)
Gamma Controls the gamma correction of pixel intensity.
