10.16 Counter And Timer Control
Controls “Timer” and “Counter”.
A) Timer Control
GenICam Parameters
TimerSelector IEnumeration Type Fixed as “Timer 0”
TimerDelay IFloat Type Delay for “Timer 0 active” signal (in µsecond)
Range: 0 to 16,777,215
Default: 0
TimerDuration IFloat Type Duration of “Timer 0 active” signal (in µsecond)
Range: 1 to 16,777,215
Default: 1
TimerTrigger
Source
IEnumeration Type Reference signal selection to generate “Timer 0 active” signal
Default: “Off”
TimerTrigger
Activation
IEnumeration Type Polarity of reference signal to generate “Timer 0 active” signal
Default: “Rising Edge”
TimerValue IFloat Type Returns value for “Timer 0 active” signal
When the timing of “Timer 0 active” signal is adjusting to active signal of Exposure, “Timer 0” can be used as
strobe control signal.
B) Counter Control
GenICam Parameters
CounterSelector IEnumeration Type Counter selection
Default: “Counter 0”
CounterEvent
Source
IEnumeration Type Counter event source selection
CounterReset
Source
IEnumeration Type Reference signal selection to reset counter
CounterReset
Activation
IEnumeration Type Polarity of reference signal to reset counter
CounterReset ICommand Type Rest switch
“Activate as switch when selecting “Software” at “Counter Reset Source”
CounterValue IInteger Type Returns number of counter
