Inverter Model Numbers
Country
E: European countries
None:Japan
Max. Applicable Motor Capacity
002: 0.2 kW
004: 0.4 kW
..
..
..
037: 3.7 kW
Voltage Class
2: 3-phase, 200 V
B: Single-phase, 200 V
Protective Structure
B: Panel-mounting
P: Optional structure
3G3SV-B2002-E
3G3SV-series
Warning
1, 2, 3...
1. After turning off the main circuit power supply, do not touch cir-
cuitcomponents untilthe “CHARGE”lampisextinguished. The
capacitors are still charged and can be quite dangerous.
2. Do not change the wiring while power is applied to the circuit.
3. Do not check signals during operation.
4. Be sure to ground 3G3SV using the ground terminal G (E).
5. Never connect main circuit output terminals, T1 (U), T2 (V), T3
(W), to AC main circuit supply.
Caution
1, 2, 3...
1. All the potentiometers of 3G3SV have been adjusted at the fac-
tory. Do not change their settings unnecessarily.
2. Do not performwithstand voltage test on any part of the 3G3SV
unit. This electronic equipment uses semi-conductors and is
vulnerable to high voltage.
1-3 Installation
1-3-1 Location
Location of the equipment is important to achieve proper perform-
ance and normal operating life.
The 3G3SV units should be installed in areas where the following
conditions exist.
Ambient temperature: +14
9
to 113
9
F, --10
9
to +50
9
C.
Protected from rain or moisture.
Protected from direct sunlight.
Protected from corrosive gases or liquids.
Free from airborne dust or metallic particles.
Free from vibration.
Free from magnetic noise.
Section 1-3
