3-34
3-7 Parameter List
3
Operation
Torque limit
b040 Torque limit selection
00: Four-quadrant separate setting
01: Terminal switch
02: Analog input
03: Option 1
04: Option 2
00 No Yes -
4-57
4-59
b041
Torque limit 1
(Four-quadrant mode
forward power
running)
0. to 200. (0.4 to 55 kW)
0. to 180. (75 to 132 kW)
no (Torque limit disabled)
150. No Yes %
4-57
4-59
b042
Torque limit 2
(Four-quadrant mode
reverse
regeneration)
0. to 200. (0.4 to 55 kW)
0. to 180. (75 to 132 kW)
no (Torque limit disabled)
150. No Yes %
4-57
4-59
b043
Torque limit 3
(Four-quadrant mode
reverse power
running)
0. to 200. (0.4 to 55 kW)
0. to 180. (75 to 132 kW)
no (Torque limit disabled)
150. No Yes %
b044
Torque limit 4
(Four-quadrant mode
forward
regeneration)
0. to 200. (0.4 to 55 kW)
0. to 180. (75 to 132 kW)
no (Torque limit disabled)
150. No Yes %
b045
Torque LADSTOP
selection
00: Disabled
01: Enabled
00 No Yes 4-59
Parameter
No.
Function name Monitor or data range
Default
setting
Changes during
operation
Unit Page
Normal
b031 = 10
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
