3-43
3-7 Parameter List
3
Operation
Analog monitor
C027 MP selection
00: Output frequency
01: Output current
02: Output torque
03: Digital output frequency
04: Output voltage
05: Input voltage
06: Thermal load rate
07: LAD frequency
08: Digital current monitor
09: Motor temperature
10: Fin temperature
12: Not used
00 No Yes 
4-106
4-116
C028 AM selection
00: Output frequency
01: Output current
02: Output torque
04: Output voltage
05: Input voltage
06: Thermal load rate
07: LAD frequency
09: Motor temperature
10: Fin temperature
11: Output torque <signed>
13: Not used
00 No Yes 
4-107
4-116
C029 AMI selection
00: Output frequency
01: Output current
02: Output torque
04: Output voltage
05: Input voltage
06: Thermal load rate
07: LAD frequency
09: Motor temperature
10: Fin temperature
14: Not used
00 No Yes 
C030
Digital current
monitor reference
value
0.20 × Rated current to 2.00 × Rated current
(Current value at the digital current monitor
output 1440 Hz)
Rated
current
Yes Yes A 4-106
Parameter
No.
Function name Monitor or data range
Default
setting
Changes during
operation
Unit Page
Normal
b031 = 10
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
