3-44
3-7 Parameter List
3
Operation
Multi-function output terminal
C031
Multi-function output
terminal P1 contact
selection
00: NO contact at MA; NC contact at MB
01: NC contact at MA; NO contact at MB
00
No Yes  4-93
C032
Multi-function output
terminal P2 contact
selection
C033
Multi-function output
terminal P3 contact
selection
C034
Multi-function output
terminal P4 contact
selection
C035
Multi-function output
terminal P5 contact
selection
C036
Relay output (MA,
MB) contact selection
01
Level and output terminal status
C038
Light load signal
output mode
00: Enabled during acceleration/
deceleration/constant speed
01: Enabled only during constant speed
01 No Yes 
4-103
C039
Light load detection
level
0.0 to 2.00 × Rated current (0.4 to 55 kW)
0.0 to 1.80 × Rated current (75 to 132 kW)
Rated
current
Yes Yes A
C040
Overload warning
signal output mode
00: Enabled during acceleration/
deceleration/constant speed
01: Enabled only during constant speed
01 No Yes 
4-49
C041
Overload warning
level
0.0: Does not operate.
0.1 × Rated current to 2.00 × Rated current
(0.4 to 55 kW)
0.1 × Rated current to 1.80 × Rated current
(75 to 132 kW)
Rated
current
Yes Yes A
C042
Arrival frequency
during acceleration
0.00 to 99.99
100.0 to 400.0
0.00 No Yes Hz
4-95
C043
Arrival frequency
during deceleration
0.00 to 99.99
100.0 to 400.0
0.00 No Yes Hz
C044
PID deviation
excessive level
0.0 to 100.0 3.0 No Yes % 4-31
C045
Arrival frequency
during acceleration 2
0.00 to 99.99
100.0 to 400.0
0.00 No Yes Hz
4-95
C046
Arrival frequency
during deceleration 2
0.00 to 99.99
100.0 to 400.0
0.00 No Yes Hz
C052
PID FB upper limit 0.0 to 100.0 100.0 No Yes %
4-31
C053
PID FB lower limit 0.0 to 100.0 0.0 No Yes %
Parameter
No.
Function name Monitor or data range
Default
setting
Changes during
operation
Unit Page
Normal
b031 = 10
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
