2 Instructions
CP1E CPU Unit Instructions Reference Manual(W483)
Floating-point Math
Instructions
2
+F, –F, *F, /F
 *F
 /F
• If the absolute value of the result is greater than the maximum value that can be expressed as float-
ing-point data, the Overflow Flag will turn ON and the result will be output as ±∞.
• If the absolute value of the result is less than the minimum value that can be expressed as floating-
point data, the Underflow Flag will turn ON and the result will be output as 0.
 Operation rules
The result of an operation is output as shown below depending on the combination of floating-point
data.
 FLOATING-POINT ADD (+F)
Note 1 The results could be zero (including underflows), a numeral, +∞, or –∞.
ER The Error Flag will be turned ON and the instruction will not be executed.
 FLOATING-POINT SUBTRACT (–F)
Note 1 The results could be zero (including underflows), a numeral, +∞, or –∞.
ER The Error Flag will be turned ON and the instruction will not be executed.
Augend
Addend 0 Numeral +∞ –∞ NaN
0 0 Numeral +∞ –∞
Numeral Numeral See note 1. +∞ –∞
+∞ +∞ +∞ +∞ ER
–∞ –∞ –∞ ER –∞
NaN ER
Minuend
Subtrahend 0 Numeral +∞ –∞ NaN
0 0 Numeral +∞ –∞
Numeral Numeral See note 1. +∞ –∞
+∞ –∞ –∞ ER
–∞
–∞ +∞ +∞ +∞ ER
NaN ER
R+1
R
Md Multiplicand (floating-point data, 32 bits)
Md+1
Mr Multiplier (floating-point data, 32 bits)
Mr+1
Result (floating-point data, 32 bits)
×
R+1
R
÷
Dd
Dividend (floating-point data, 32 bits)
Dd+1
Dr
Divisor (floating-point data, 32 bits)
Dr+1
Result (floating-point data, 32 bits)
