4-2SectionMemory Map of Data Carrier
30
To not protect addresses:
Address Higher digits Lower digits
0002 0 0 0 0 0 0 0 0
0 0
0003 0 0 0 0 0 0 0 0
0 0
0004 0 0 0 0 0 0 0 0
0 0
0005 0 0 0 0 0 0 0 0
0 0
Example of Setting Write Protect Function
1, 2, 3... 1. To write-protect addresses 0015 through 0120. (End address)
Address Bit
7 6 5 4 3 2 1 0
0002 1 0 0 0 0 0 0 0
8 0
0003 0 0 0 1 0 1 0 1
1 5
0004 0 0 0 0 0 0 0 1
0 1
0005 0 0 1 0 0 0 0 0
2 0
2. To write-protect only 1 byte <start address = end address> Set the same ad-
dress as the start and end addresses.
3. If the end address exceeds the last address of the Data Carrier memory
(end address > 07FF):
Since the memory area of the Data Carrier is from 0000 through 07FF, ad-
dresses up to 07FF are write-protected.
4. If start address exceeds end address (start address > end address):
Addresses from 0006 through end address, and start address through 07FF
are write-protected.
