5-3 Error Lists
Communication Error
Location Error
code
Type Condition
Host
10 Parity error
Error occurs during communication between host
communication
error
11 Framing error
computer and ID Controller.
– Incorrect setting of communication format
12 Overrun error
– Malfunctioning due to noise
14 Command input error Wrong command format.
18 Frame length MAX error Command or data length exceeding 266 characters.
Lower
communication
error
70 Data carrier communication error Error during communication between R/W Head and
DC.
– Setting error such as passing speed and distance
– Malfunctioning due to obstacle
71 Unmatching error Read or write processing is not performed correctly.
72 Data carrier missing DC does not exist in specified area when write/read
command is executed.
7A Address over Address exceeding memory area of DC is specified.
7C R/W head not connected R/W Head is not connected.
7D Write protect error Production date area or write-protected area is specified
for write command.
Note 1. The host communication error is an error that has occurred during commu-
nications between the host computer and ID Controller.
2. The lower communication error is an error that has occurred during commu-
nications between the ID Controller and R/W Head. These errors are all re-
corded in the ID Controller and their error codes and messages can be read
using a command from the host computer.
3. These errors are all recorded in the ID Controller and their error codes can
be read using a command from the host computer.
Warning Code
Warning Code Name Meaning
7B Data carrier battery low The voltage of the Data Carrier’s built-in battery is low.
76 Excessive number of Data Carrier
overwriting operations
This warning will be returned when the data
management command (MDL) is executed if the number
of Data Carrier overwriting operations is 100,000 or
over.
76 Data Carrier memory check error This warning will be returned if a memory error is
detected when the memory check command (MDC) is
executed.
System Error
Error
code
Type Condition
92 CPU error
May be due to an ID Controller error or the influence of noise. Turn OFF power once and
93 Memory error
then turn it back ON again. Turn ON the reset input (if the error still persists, use the other ID
Controller).
Note The system error (error that stops the operation) can be displayed on the monitor
of the ID Controller but cannot be checked by the host computer.
