105
RFID System
Operation Manual
Section 5 Communications Commands
Section 5
Communications
1:N Communications
Data code specification Always “H” (hexadecimal code).
R/W Head No. Specifies the Read/Write Head with which to communicate.
1: Read from Read/Write Head 1 and write to Read/Write Head 2.
2: Read from Read/Write Head 2 and write to Read/Write Head 1.
Read area start address Specifies the first address from which to read data from the Data Carrier as a four-digit hexadeci-
mal number.
Specifiable range: 0000H to FFFFH
No. of bytes to copy Specifies the number of bytes of data to copy as a four-digit hexadecimal number.
Specifiable range: 0001H to 0800H
Copy destination write start
address
Specifies the first address to which to write data to the Data Carrier as a four-digit hexadecimal
number.
Specifiable range: 0000H to FFFFH
End code Indicates the results of command execution. An end code of 00 is returned for a normal end.
Refer to End Codes for more information.
p.135
Terminator
xx
CP
xx
H
xx
211 4
xx
4
1/2
xx
xx
4
2
*CR
2
xx
FCS
3
x
@
x
Read area start address
Controller No.
Command code
Data code
specifica-
tion
No. of bytes to copy
Copy destination write start address
R/W Head No.
Command
Response
Command code
CP
00
22
2
*CR
Terminator
End code
2
xx
FCS
3
Controller No.
x
@
x
