Section 5 Communications Commands
RFID System
Operation Manual
Section 5
Communications
AUTO COPY (AP)
For AUTO COPY, the ID Controller waits until a Data Carrier approaches and then Writes data read
from Data Carrier memory by one Read/Write Head to the memory of a Data Carrier in the
communications area of the other Read/Write Head.
The data is always written to the destination Data Carrier on the trigger.
■ 1:1 Communications
Data code specification Always “H” (hexadecimal code).
R/W Head No. Specifies the Read/Write Head with which to communicate.
1: Read from Read/Write Head 1 and write to Read/Write Head 2.
2: Read from Read/Write Head 2 and write to Read/Write Head 1.
Read area start address Specifies the first address from which to read data from the Data Carrier as a four-digit hexadeci-
mal number.
Specifiable range: 0000H to FFFFH
No. of bytes to copy Specifies the number of bytes of data to copy as a four-digit hexadecimal number.
Specifiable range: 0001H to 0800H
Copy destination write start
address
Specifies the first address to which to write data to the Data Carrier as a four-digit hexadecimal
number.
Specifiable range: 0000H to FFFFH
End code Indicates the results of command execution. An end code of 00 is returned for a normal end.
Refer to End Codes for more information.
p.135
xx
AP
xx
H
xx
211 4
xx
4
2
*CR
1/2
xx
xx
4
Read area start address
Command code
Data code
specifica-
tion
No. of bytes to copy
Copy destination write
start address
Terminator
R/W Head No.
Command
Response
Command code
AP
00
22
2
*CR
Terminator
End code

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
