Section 2 Wiring
RFID System
Operation Manual
Section 2
Installation and Wiring
RS-422/RS-485 Port
Pin Arrangement
■ Connecting to the Host Device
■ RS-422 Connection
The +/ polarity designations for the SDA, SDB, RDA, and RDB signals are reversed on some devices. Always check
the signal names of the connected device and connect the polarity correctly.
■ RS-485 Connection
The internal circuits are as follows:
Pin No. Name Description
1RDA() Receive data
2 RDB(+) Receive data
3SDA() Send data
4 SDB(+) Send data
5SGSG
*Using RS-485 is possible by shorting pins 1 and 3 and
pins 2 and 4, and changing the setting to RS-485.
Note. Ground the shield at the host device to prevent malfunctions.
Note. Short pins 1 and 3 and pins 2 and 4 Do not connect
anything to the ID Controller's SG.
Pin No.
12345
• Pin Arrangement
ID Controller
Host device
(Shield)
RDA()
RDB()
SDA()
SDB()
SG
SDA()
SDB()
RDA()
RDB()
SG
GR
ID Controller
RDA()
RDB()
SDA()
SDB()
SG


Host device
Receiving side
terminating resistance
Sending side
terminating resistance
RDA() RDB()SDA()SDB()SG
Terminating resistance: RS-422: 220
, RS-485: 110 
Note: Turn ON the terminating resistance at the nodes on both ends of the main cable.
Turn OFF the terminating resistance at all other nodes. Normal transmissions will not
be possible if the terminating resistance is ON at any node other than the end nodes.

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
