Omron V600 Series User Manual

40
Section 2 Wiring
RFID System
Operation Manual
Section 2
Installation and Wiring
Windows XP (SP1)
1. Turn ON the power to the personal computer and start Windows XP.
2. Connect the ID Controller to the personal computer using the USB interface.
Refer to USB Port for more information.
p.34
Wait for the following window to be displayed.
3. When the following window is displayed, select Install from a list or specific location (Advanced) and
click the Next Button.
4. Click the Browse Button, select the folder in which the downloaded file V600-CA5D_100.inf is saved,
and then click the Next Button.

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
