Influence of Background Metals (Reference Only)
The CIDRW Head can also communicate from an opening in a ceiling panel (metal body).
However, ensure the distances indicated below between the CIDRW Head and the metal body. If you
do not ensure these distances the communications distance will be substantially shortened.
Metal body (material: AL, SUS)
(Thickness: 1 mm)
V640-HS62
CIDRW HEAD
MADE IN JAPAN
20 mm min.
20 mm min.
30 mm min.
30 mm min.
Metal body (material: AL, SUS)
