■ Same Write
Writes the same data to multiple pages of an ID Tag.
Any page(s) can be specified.
Data Segment Area Refer to page 125.
The response code (when normal: 00) is returned.
Example: Clearing pages 1 to 17 of node No.1 to 0
Parameter description
Parameter Description
Page designation Pages are specified by setting the bits corresponding to pages that are to be read to 1 and setting
the other bits to 0, then converting the result to a hexadecimal character string.
Write data Specify the write data.
SOH Node No.
Response
code
FCS CR
01h 0 0 0Dh
SOH Node No.
Response
code
FCS CR
01h0100010Dh
Command
SOH Node No. Command code Page designation (8 characters)
Write data
FCS CR
Data 1 ⋅ ⋅ ⋅ Data 8
01h 0 3 0 0 0DH
Bit 7-07 -321076-1076 -210
PageSys-SysSys-Sys1716151413-8765 -1SysSys
Designation 0* 0* 0* 0* 0* 0/1 0/1 0/1 0/1 0/1 ••• 0/1 0/1 0/1 0/1 ••• 0/1 0* 0*
Value 00 00 - 07 00 - FF 00 - FC
* Always specify 0. If you specify 1 an error (Response code: 14) will occur.
Response
Command
00000000000001111111111111111100
Binary notation
SOH Node No.
Command
code
Page designation Write data FCS CR
01h 0 1 03000007FFFC0000000000000000 0 0 0Dh
Response
To Next Page
