130
SECTION 6
SECS Protocol Specifications
CIDRW System
User’s Manual
SECTION 6
Appendix
Support Attributes
CIDRW attribute definitions
Attribute names Description Access
Re-
quest
Format and mounting
Basic items Configuration Number of CIDRW Heads RO Y 20 "00"-"31"
The number of heads connected
when the system power is turned
ON (automatic recognition)
AlarmStatus Substate of current CIDRW
alarms
RO Y 20
"0" = no alarm
"1" = alarm has occurred
OperationalStatus Substate of current CIDRW
operations
RO Y 20
"IDLE"
"BUSY"
"MANT"
SoftwareRevisionLevel Software revision (version) RO Y 20 6byte
"VVV.RR"
(VVV = version, RR = revision)
CarrierIDOffset The position of the offset,
referenced to the first byte
of the carrier ID in the tag.
RW N 20 00-15
However, (CarrierIDOffset +
CarrierIDLength) ≤ 16.
CarrierIDlength The number of bytes in the
carrier ID (if there are any
non-visible ASCII charac-
ters in the carrier ID, the
CIDRW returns an error to
the host controller.
RW N 20 01-16
However, (CarrierIDOffset +
CarrierIDLength) ≤ 16.
Option DateInstalled Date on which the sub-
system was installed
RW N 20 8 bytes
All " " (space) on shipping
DeviceType CIDR / CIDRW classifica-
tion
RO N 20 5 bytes
"CIDRW"
HardwareRevisionLevel Hardware revision number RO N 20 6 bytes
"VVV.RR"
(VVV = version, RR = revision)
MaintenanceData Supplier dependent RW N 20 80 bytes
All " " (space) on shipping
Manufacturer Manufacturer's name or ID RO N 20 17 bytes
"OMRON Corporation"
ModelNumber Model name according to
the maker
RO N 20 6 bytes
"L22 "
SerialNumber System serial number RO N 20 max. 20 bytes
(Not supported by the CIDRW)
