SECTION 5
When SECS is Used
CIDRW System
User’s Manual
SECTION 5
Troubleshooting
■ Setting Mode
• Operating normally in the Setting mode
Terminal initial screen of the host device after startup in the Setting mode
Terminal screen when parameter setting has been completed without error
Indicators
POWER OPERATING ALARMS BUSY ERROR
Error occurrence
All LEDs are lit
or flashing.
POWER-LED is OFF
No
Yes
No
Yes
An error has occurred in the CIDRW Controller power supply.
Check the power supply of the CIDRW Controller.
An error has occurred at the CIDRW Controller.
Check the status of the indicators.
When all the LEDs are lit or flashing Refer to page 93.
Check if the CIDRW Controller settings are correct.
When the CIDRW Controller fails to respond to messages sent to it Refer to page 93.
When an error unrelated to message transmission and responses occurs Refer to page 93.
SETUP_START <L22 ><XXX.XX, YYY.YY>
_
Software Revision Level
Model number
Hardware Revision Level
SETUP_COMPLETE
_
To Next Page
