Reading from/Writing to ID Tags
Example: Writing data to pages 8 and 10 of node No.1
The ID Tag status on normal completion is as shown below.
SOH Node No.
Response
code
FCS CR
01h0100010Dh
Page 8 11h 22h 33h 44h 55h 66h 77h 88h
Page 9
Page 10 01h 23h 45h 67h 89h ABh CDh EFh
Command
00000000000000000000101000000000
SOH
Node
No.
Command
code
Page designation Data of page 8 Data of page 10 FCS CR
01h 0 1 0 2 0 000000A0011223344556677880123456789ABCDEF 7 4 0Dh
Binary notation
Response
To Next Page
