35
En
Menu HDMI Input
If you connect a video component to an HDMI input, you
must assign that input to an input selector. For example, if
you connect your Blu-ray Disc/DVD player to HDMI
IN 2, you must assign “HDMI2” to the “BD/DVD” input
selector.
Here are the default assignments.
BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX,
TV/CD
` HDMI1, HDMI2, HDMI3, HDMI4:
Select a corresponding HDMI input that the video
component has been connected.
` -----:
Select if you’re not using the HDMI OUT.
Each HDMI input cannot be assigned to two input
selectors or more. When HDMI1 - HDMI4 have
already been assigned, you must set first any unused
input selectors to “-----”, or you will be unable to
assign HDMI1 - HDMI4 to input selector.
Note
•When an HDMI IN is assigned to an input selector as explained
here, the digital audio input for that input selector is
automatically set to the same HDMI IN.
Do not assign the component connected with the HDMI input to
TV/CD selector when you set “HDMI Ctrl (RIHD)” setting to
On” ( page 42). Otherwise, appropriate CEC (Consumer
Electronics Control) operation will not be guaranteed.
Menu Component
If you connect a video component to a component video
input, you must assign that input to an input selector. For
example, if you connect your Blu-ray Disc/DVD player to
COMPONENT VIDEO IN 2, you must assign “IN2” to
the “BD/DVD” input selector.
Here are the default assignments.
BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX,
TV/CD
` IN1, IN2:
Select a corresponding component video input that
the video component has been connected.
` -----:
Select if you’re not using the COMPONENT
VIDEO OUT.
Menu Digital Audio
If you connect a component to a digital audio input, you
must assign that input to an input selector. For example, if
you connect your CD player to the OPTICAL IN 1, you
must assign “OPTICAL1” to the “TV/CD” input
selector.
Here are the default assignments.
BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX,
TV/CD
` COAXIAL1, COAXIAL2, OPTICAL1,
OPTICAL2:
Select a corresponding digital audio input that the
component has been connected.
` -----:
Select if the component is connected to an analog
audio input.
Note
When an HDMI IN is assigned to an input selector in
“HDMI Input” ( page 35), this input assignment is
automatically set to the same HDMI IN. And in addition to the
usual inputs (e.g., COAXIAL1, COAXIAL2, etc.), you can also
select HDMI inputs.
Available sampling rate for PCM signals from a digital input
(optical and coaxial) is 32/44.1/48/88.2/96 kHz/16, 20, 24 bit.
HDMI Input
Input selector Default assignment
BD/DVD HDMI1
VCR/DVR HDMI2
CBL/SAT HDMI3
GAME HDMI4
AUX -----
TV/CD -----
Component (Component Video Input)
Input selector Default assignment
BD/DVD IN1
VCR/DVR - - - - -
CBL/SAT IN2
GAME -----
AUX -----
TV/CD -----
Digital Audio (Digital Audio Input)
Input selector Default assignment
BD/DVD COAXIAL1
VCR/DVR - - - - -
CBL/SAT COAXIAL2
GAME OPTICAL1
AUX -----
TV/CD OPTICAL2
