36
En
Menu Sp Config
Here you can check the settings made by Audyssey 2EQ
Room Correction and Speaker Setup, or set them
manually, which is useful if you change one of the
connected speakers after using Audyssey 2EQ Room
Correction and Speaker Setup.
This section explains how to specify
which speakers are connected and their
sizes.
For speakers with a cone diameter larger
than 6-1/2 inches (16 cm), specify Large
(full band). For those with a smaller
diameter, specify Small (default crossover 100 Hz).
The crossover frequency can be changed in the
“Crossover (Crossover Frequency)” (➔ page 36).
Note
• These settings are not available in either of the following cases:
– a pair of headphones is connected.
–the “Audio TV Out” setting is set to “On” (➔ page 42).
–“HDMI Ctrl (RIHD)” is set to “On” (➔ page 42) and
you’re listening through your TV speakers.
■ Subwoofer
` Yes
` No
■ Front
` Small
:
` Large:
Select based on the cone diameter.
Note
•If the “Subwoofer” setting is set to “No”, this setting is fixed at
“Large” and does not appear.
■ Center
*1
, Surround
*1
,
Front High
*1*2*3*4*5
,
Surround Back
*1*2*3*6
` Small:
` Large:
Select based on the cone diameter.
` None:
Select if no speaker is connected.
Note
*1
If the “Front” setting is set to “Small”, the “Large” option
cannot be selected.
*2
If the “Surround” setting is set to “None”, this setting cannot
be selected.
*3
If the “Surround” setting is set to “Small”, the “Large”
option cannot be selected.
*4
For “Front High”, the default is “None”.
*5
If the “Surround Back” setting is set to other than “None”,
this setting is set to “None”.
*6
If the “Front High” setting is set to other than “None”, this
setting is set to “None”.
■ Surround Back Ch
` 1ch:
Select if only one surround back speaker is
connected.
` 2ch
:
Select if two (left and right) surround back speakers
are connected.
Note
•If the “Surround Back” setting is set to “None”, this setting
cannot be selected.
■ Crossover (Crossover Frequency)
This setting is advantageous for the speakers that you
specified as “Small” in the “Sp Config (Speaker
Configuration)” (➔ page 36). To get the best bass
performance from your speaker system, you need to set
the crossover frequency according to the size and
frequency response of your speakers.
` 40Hz, 50Hz, 60Hz, 70Hz, 80Hz, 90Hz, 100Hz,
120Hz, 150Hz, 200Hz
Use the diameter of the smallest speaker in your system
when choosing the crossover frequency.
*
Choose the setting suitable for the speaker.
Note
• For a more accurate setting, look up the frequency response in
the manuals supplied with your speakers and set accordingly.
• Choose a higher crossover frequency if you want more sound
from your subwoofer.
■ Double Bass
` On
` Off
Turn this setting on to boost bass output by feeding bass
sounds from the front left, right, and center channels to the
subwoofer.
Note
• This function can be set only if the “Subwoofer” setting is set to
“Yes”, and the “Front” setting is set to “Large” (➔ page 36).
Sp Config (Speaker Configuration)
Some of the settings in this section are set automatically
by Audyssey 2EQ
®
Room Correction and Speaker
Setup (➔ page 24).
Cone diameter
Speaker cone diameter Crossover frequency
Over 8 in. (20 cm)
40/50/60 Hz
*
6-1/2 to 8 in. (16 to 20 cm)
70/80/90 Hz
*
5-1/4 to 6-1/2 in. (13 to 16 cm) 100 Hz
3-1/2 to 5-1/4 in. (9 to 13 cm) 120 Hz
Under 3-1/2 in. (9 cm)
150/200 Hz
*
This setting is not set automatically by Audyssey 2EQ
Room Correction and Speaker Setup (➔ page 24).
