Page #37 background imageLoading...
Page #37 background image
37
En
Menu Sp Distance
Here you can specify the distance from each speaker to the
listening position so that the sound from each speaker
arrives at the listener’s ears as the sound designer
intended.
Unit
` feet:
Distances can be set in feet. Range: 1ft to 30ft in
1 foot steps.
` meters:
Distances can be set in meters. Range: 0.3m to 9.0m
in 0.3 meter steps.
(The default setting varies from country to country.)
Left, Front High Left, Center, Front High Right,
Right, Surround Right, Surr Back Right, Surr
Back Left, Surround Left, Subwoofer
` Specify the distance from the each speaker to your
listening position.
Note
These settings are not available in either of the following cases:
a pair of headphones is connected.
–theAudio TV Out” setting is set to “On” ( page 42).
–“HDMI Ctrl (RIHD)” is set to On” ( page 42) and
you’re listening through your TV speakers.
Speakers that you set to “No” or “None” in the “Sp Config
(Speaker Configuration)” ( page 36) cannot be selected.
Menu Level Cal
Here you can adjust the level of each speaker with the
built-in test tone so that the volume of each speaker is the
same at the listening position.
Left, Front High Left, Center
*1
, Front High Right,
Right, Surround Right, Surr Back Right, Surr
Back Left, Surround Left
` –12 dB to 0dB
to +12 dB in 1 dB step.
Subwoofer
*1
` –15 dB to 0dB to +12 dB in 1 dB step.
Note
These settings cannot be calibrated in either of the following
cases:
a pair of headphones is connected.
–theAudio TV Out” setting is set to “On” ( page 42).
–“HDMI Ctrl (RIHD)” is set to On” ( page 42) and
you’re listening through your TV speakers.
the AV receiver is muted.
Speakers that you set to “No” or “None” in the “Sp Config
(Speaker Configuration)” ( page 36) cannot be selected.
*1
For the center speaker and subwoofer, the level settings made
by using HOME are saved here as the default settings.
Tip
If you’re using a handheld sound level meter, adjust the level of
each speaker so that it reads 75 dB SPL at the listening position,
measured with C-weighting and slow reading.
Menu Audio Adjust
With the Audio Adjust functions and settings, you can
adjust the sound and listening modes as you like.
Multiplex/Mono Settings
Multiplex
Input Ch (Mux)
` Main
` Sub
` Main/Sub
This setting determines which channel of a stereo
multiplex source is output. Use it to select audio channels
or languages with multiplex sources, multilingual TV
broadcasts, and so on.
Mono
Input Ch (Mono)
` Left + Right
` Left
` Right
This setting specifies the channel to be used for playing
any 2-channel digital source such as Dolby Digital, or 2-
channel analog/PCM source in the Mono listening mode.
Sp Distance (Speaker Distance)
This setting is set automatically by Audyssey 2EQ
®
Room Correction and Speaker Setup ( page 24).
Level Cal (Level Calibration)
This setting is set automatically by Audyssey 2EQ
Room Correction and Speaker Setup ( page 24).
