Page #43 background imageLoading...
Page #43 background image
43
En
LipSync
` Off
` On
This function allows the AV receiver to automatically
correct any delay between the video and the audio, based
on the data from the connected monitor.
Note
This function works only if your HDMI-compatible TV supports
HDMI Lip Sync.
You can change various audio settings from the Home
menu ( page 31).
Note
These settings are not available in either of the following cases:
a pair of headphones is connected.
–theAudio TV Out” setting is set to “On” ( page 42) and
an input selector other than HDMI is selected.
–“HDMI Ctrl (RIHD)” is set to On” ( page 42) and
you’re listening through your TV speakers.
Tone Control Settings
Bass
` –10 dB to 0dB
to +10 dB in 2 dB steps
You can boost or cut low-frequency sounds output
from the front speakers.
Treble
` –10 dB to 0dB
to +10 dB in 2 dB steps
You can boost or cut high-frequency sounds output
from the front speakers.
You can adjust the bass and treble for the front speakers,
except when the Direct listening mode is selected.
Operating on the AV receiver
Note
To bypass the bass and treble tone circuits, select the Direct
listening mode.
Speaker Levels
Subwoofer Level
*1
` –15 dB to 0dB to +12 dB in 1 dB steps
Center Level
` –12 dB to 0dB
to +12 dB in 1 dB steps
You can adjust the volume of each speaker while listening
to an input source.
These temporary adjustments are cancelled when the AV
receiver is set to Standby. To save the setting you made
here, go to “Level Cal (Level Calibration)” ( page 37)
before setting the AV receiver to Standby.
Note
You cannot use this function while the AV receiver is muted.
Speakers that are set to “No” or “None” in the “Sp Config
(Speaker Configuration)” ( page 36) cannot be adjusted.
*1
This procedure can also be performed on the AV receiver by
using its SUBWOOFER LEVEL.
Audyssey
Audyssey
See “Audyssey” of “Source Setup” ( page 39).
Dynamic EQ
See “Dynamic EQ” of “Source Setup” ( page 39).
Dynamic Volume
See “Dynamic Volume” of “Source Setup” ( page 39).
Note
These technologies can be used when all the following
conditions are met:
Room Correction and Speaker Setup is completed. Note that
Audyssey” requires the “Audyssey 2EQ Full Calibration
method.
Any listening mode other than Direct is selected.
A pair of headphones is not connected.
The input selector other than USB is selected.
The setting is stored individually for each input selector.
After changing the settings of the “HDMI Ctrl
(RIHD)”, “HDMI Through” or “Audio Return Ch”,
turn off the power to all connected pieces of equipment
and then turn them on again. Refer to the instructions
for all connected pieces of equipment.
Using the Audio Settings
1
Press RECEIVER followed by HOME.
2
Use q/w and ENTER to select “Audio”, and then
use q/w/e/r to make the desired selection.
1
Press TONE on the AV receiver repeatedly to
select either “Bass” or “Treble”.
2
Use + and on the AV receiver to adjust.
