Onkyo P-3000R User Manual

16
En
Tip
• To reduce noise, do not tie the signal cable and power cable
together. Wire them so that they are away from each other.
Note
• Never disconnect the power cord from the preamplifier while
the other end is still plugged into a wall outlet. Doing so may
cause an electric shock. Always disconnect the power cord from
the wall outlet first, and then the preamplifier.
• Turning on the preamplifier may cause a momentary power
surge that might interfere with other electrical equipment on the
same circuit. If this is a problem, plug the preamplifier into a
different branch circuit.
• Do not use a power cord other than the one supplied with the
preamplifier. The supplied power cord is designed exclusively
for use with the preamplifier and should not be used with any
other equipment.
Connecting the Power Cord
AC INLET
Preamplifier P-3000R
Supplied power cord
To an AC wall outlet
(Plug type varies from
country to country.)
1
Make sure that the main power of the preamplifier
is turned off.
2
Connect all of your components.
3
Connect the supplied power cord to the
preamplifier’s AC INLET.
4
Plug the power cord into an AC wall outlet.

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
