Onkyo P-3000R User Manual

38
En
Specifications
■ Audio Inputs
■ Audio Outputs
■ Others
■ System Requirements
Specifications and features are subject to change without notice.
Windows and the Windows logo are trademarks of the Microsoft group of companies.
P-3000R
THD+N (Total Harmonic Distortion+Noise) 0.005 % (20 Hz - 20 kHz, Power Rated)
Input Sensitivity and Impedance (Unbalance) 200 mV/47 kΩ (LINE)
2.7 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance 1 V/330 Ω (PRE OUT)
Maximum RCA Output Level and Impedance 5.0 V/ 330 Ω (PRE OUT)
Phono Overload 80 mV (MM 1 kHz 0.5 %)
Frequency Response 5 Hz-100 kHz/+0, –3 dB (LINE)
Tone Control Characteristies ±8 dB, 50 Hz (BASS)
±8 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (Direct, IHF-A)
80 dB (PHONO, IHF-A)
Power Supply (North American)
AC 120 V, 60 Hz
(European) AC 230 V, 50 Hz
Power Consumption (North American) 26 W
(European) 29 W
Standby Power Consumption (North American) 0.2 W
(European) 0.3 W
Dimensions (W × H × D) 435 W × 99 H × 333.1 D mm
(17-1/8" W × 3-7/8" H × 13-1/8" D inches)
Weight 11.0 kg (24.3 lbs.)
Digital Inputs Optical: 2
Coaxial: 2
2ch PCM
Digital Input Sampling Rate:
32 kHz/44.1 kHz/48 kHz/88.2 kHz/96 kHz
compatible (OPT)
32 kHz/44.1 kHz/48 kHz/88.2 kHz/96 kHz/
176.4 kHz/192 kHz compatible
(COAX, AES/EBU)
44.1 kHz/48 kHz/96 kHz/192 kHz compatible
(USB)
Analog Stereo Inputs PHONO, CD, LINE 1, LINE 2, TAPE (LINE 3)
Balance Inputs AES/EBU (DIGITAL)
Digital Outputs Optical: 1
Digital Output Sampling Rate:
32 kHz/44.1 kHz/48 kHz/88.2 kHz/96 kHz
compatible (OPT)
Analog Stereo Outputs TAPE (LINE)
Pre Outputs 2
Phones 1 (6.3 ø)
12V Trigger Out 1
RI 1
PC Interface USB
USB 1
OS
Windows
®
7 (32 bits/64 bits)/Windows Vista
®
(32/64 bits)/Windows
®
XP (32/64 bits) SP3 or
later
CPU
Intel
®
Pentium
®
4 processor 1.6 GHz or higher
processor
RAM 512 MB or greater
HDD 60 MB or greater free hard drive space
Supported models PC/AT compatible machine equipped with a
USB port compliant with the USB standard
Rev2.0 HS (Intel
®
USB host controller is
recommended)

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
