Onkyo P-3000R User Manual

27
En
You can adjust the bass, treble and balance.
Note
• The preamplifier will end the setup if there is no operation for
8 seconds.
• The tone controls are canceled when the Direct function is set to
on.
Adjusting the Bass, Treble and Balance
1
Press SETUP.
2
Press #/$ to select “BASS”, “TREBLE” or
“BALANCE”.
SETUP
#, $
ENTER
3
Press ENTER.
4
Press #/$ to adjust the value.
The setting has been established.
` BASS
` TREBLE
The value changes by 2 dB and can be set from –
8 dB to +8 dB.
` BALANCE
The left and right output balance can be adjusted.
To cancel the setup at any point, press SETUP.
You can also use preamplifier’s MODE and Multi jog
dial.
See “Using MODE button” to perform this procedure
on the preamplifier (➔ 29).
Note
While preamplifier is muted:
• Turning the Volume controller on the preamplifier or pressing
VOLUME q/w on the remote controller will unmute the
preamplifier.
• If you turn the preamplifier off, the next time you turn it on, the
preamplifier will be unmuted.
Muting the Sound
1
Press MUTING to mute the out of the preamplifier.
The MUTING indicator flashes on the display.
To unmute the preamplifier, press MUTING again.
MUTING
MUTING indicator

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
